Applications
- Indoor and outdoor;
- Environments with high levels of dust and vapours:
- production shops;
- warehouses;
- hangars;
- storage facilities;
- car parks and sheds;
- car washes, etc.
Main features
- Modular design with 0.5m modules;
- Every individual module is AC powered and dimmed on a stand-alone basis;
- Surge protection;
- Over-temperature protection over 85˚С;
- Lower power consumption;
- UV-, acid- and alkali-resistant diffuser;
- P66;
- Light weigh for installation on wire ropes, cable trays, etc.
- Water-washable;
- Low-cost dimming system;
- Class II Electrical Safety;
Light distribution diagram, cd/1,000 lm (normalized diagram) 90x110º «D» (cosine)
Power
|
15W
|
Voltage / Frequency
|
176-276V/ 50Hz
|
Dimensions, ØxL,
|
58х600 mm
|
Power factor
|
Ю0,92
|
Luminous flux @ 4,000 К
|
1,600 lm
|
Efficacy
|
106 lm/W
|
Light distribution diagram, cd/1,000 lm
|
90x110º «D» (cosine)
|
CRI, Ra
|
70, 80, 90
|
Ingress protection
|
IP66
|
Operating temperatures
|
-40°С to +40°С
|
Luminaire lifecycle
|
50,000 hrs
|
Electrical Safety Classification
|
II
|
Wire section
|
2х0.75mm²
|
Weight
|
0.8kg
|
PC extruded LED fixtures come in different lengths from 0.3 to 3 m and wattages from 5 to 150W. Luminaires can be built into lines.
Opal diffuser guarantees comfortable light.
IP65 provided dust and water protection.
Colour temperature customisation:
- 2,700 - 3,400 К (warm light)
- 3,500 - 4,600 К (neutral light)
- 4,700 - 6,500 К (cold light)
Industrial LED Luminaire 255W Suspended (INDUSTRY.3)
Product code: INDUSTRY.3-270-160/160
Power
|
255W
|
Luminous flux @ 4,000К
|
34,500
|
Luminous flux @ 5.000К
|
34,500
|
Efficacy
|
135lm/W
|
Ingress protection
|
IP67
|
Industrial LED Batten 44W (INDUSTRY.P)
Product code: INDUSTRY.P44
Power
|
44W
|
Luminous flux @ 4,00К
|
4,200
|
Luminous flux @ 5,00К
|
4,250
|
Efficacy
|
96lm/W
|
Ingress protection
|
IP65
|
Industrial LED Luminaire 420W Suspended (INDUSTRY.3)
Product code: INDUSTRY.3-430-248/248
Power
|
420W
|
Luminous flux @ 4,000К
|
54,400
|
Luminous flux @ 5.000К
|
54,400
|
Efficacy
|
130lm/W
|
Ingress protection
|
IP67
|
Industrial LED Luminaire 510W Suspended (INDUSTRY.3)
Product code: INDUSTRY.3-540-260/260
Power
|
510W
|
Luminous flux @ 4,000К
|
69,000
|
Luminous flux @ 5.000К
|
69,000
|
Efficacy
|
135lm/W
|
Ingress protection
|
IP67
|
Customisation
- Colour temperature (3,000-5,000K)
- Length
- Diffuser
